Unit
NUmber |
Shaft
Dia. |
h |
a |
e |
b |
S1 |
S2 |
g |
w |
Bi |
n |
Bolt
Size |
|
|
SAPE 201-8 |
1/2" |
1-3/16" |
4-7/8" |
3-3/4" |
1-7/32" |
7/16" |
19/32" |
9/16" |
2-1/4" |
1.126 |
0.236 |
3/8" |
|
|
SAPE 202-10 |
5/8" |
|
|
SAPE 204-12 |
3/4" |
1-5/16" |
5" |
3-3/4" |
1-1/2" |
1/2" |
5/8" |
19/32" |
2-9/16" |
1.220 |
0.276 |
3/8" |
|
|
SAPE 205-14 |
7/8" |
1-7/16" |
5-1/2" |
4-1/8" |
1-1/2" |
1/2" |
5/8" |
5/8" |
2-3/4" |
1.220 |
0.295 |
3/8" |
|
|
SAPE 205-15 |
15/16" |
|
|
SAPE 205-16 |
1" |
|
|
SAPE 206-17 |
1-1/16" |
1-11/16" |
6-1/2" |
4-49/64" |
1-7/8" |
21/32" |
13/16" |
23/32" |
3-9/32" |
1.406 |
0.315 |
1/2" |
|
|
SAPE 206-18 |
1-1/8" |
|
|
SAPE 206-19 |
1-3/16" |
|
|
SAPE 206-20 |
1-1/4" |
|
|
SAPE 207-20 |
1-1/4" |
1-7/8" |
6-9/16" |
5" |
1-7/8" |
21/32" |
13/16" |
3/4" |
3-11/16" |
1.531 |
0.335 |
1/2" |
|
|
SAPE 207-21 |
1-5/16" |
|
|
SAPE 207-22 |
1-3/8" |
|
|
SAPE 207-23 |
1-7/16" |
|
|
SAPE 208-24 |
1-1/2" |
1-15/16" |
7-1/4" |
5-25/64" |
2-1/8" |
21/32" |
31/32" |
3/4" |
3-15/16" |
1.720 |
0.354 |
1/2" |
|
|
SAPE 208-25 |
1-9/16" |
|
|
SAPE 209-26 |
1-5/8" |
2-1/8" |
7/15/32" |
5-3/4" |
2-1/8" |
21/32" |
31/32" |
25/32" |
4-1/4" |
1.720 |
0.374 |
1/2" |
|
|
SAPE 209-27 |
1-11/16" |
|
|
SAPE 209-28 |
1-3/4" |
|
|
SAPE 210-30 |
1-7/8" |
2-1/4" |
8-1/8" |
6-1/4" |
2-3/8" |
25/32" |
31/32" |
7/8" |
4-1/2" |
1.720 |
0.394 |
5/8" |
|
|
SAPE 210-31 |
1-15/16" |
|
|
SAPE 210-32 |
2" |
|
