Dimensions         inch
Set # Bearing
Number		 d D B C T
Set 1 LM 11710   1.570   0.420 0.545
LM11749/LM11710
$3.26
  LM 11749 0.687   0.575
Set 2 LM 11910   1.781   0.475 0.610

LM11949/LM11910
$3.29

  LM 11949 0.750   0.655
Set 3 M 12610   1.968   0.550 0.690

M12649/M12610
$4.37

  M 12649 0.843   0.720
Set 4 L 44610   1.980   0.420 -

L44649/L44610
$3.64

  L 44649 1.062   0.580
Set 5 LM 48510   2.562   0.550 -

LM48548/LM48510
$5.86

  LM 48548 1.375   0.720
Set 6 LM 67010   2.328   0.465 -

LM 67048/10
$3.97

  LM 67048 1.250   0.660
Set 8 L 45410   1.980   0.420 0.560

L45449/L45410
$4.06

  L 45449 1.1417   0.580
Set 11 JL 69310   2.4803   0.5315 0.6693

JL69349/JL69310
$5.92

  JL 69349 1.4961   0.6693
Set 12 LM 12710   1.7810   0.4750 0.6100

LM12749/LM12710
$3.68

  LM 12749 0.8656   0.6550
Set 13 L 68110   2.3280   0.4700 0.6250

L68149/L68110
$4.36

  L 68149 1.3775   0.6600
Set14 L 44610   1.9800   0.4200 0.5600

L44643/L44610
$3.55

  L 44643 1.000   0.5800
Set16 LM 12711   1.8110   0.4750 0.6100

M12749/M12711
$3.89

  LM 12749 0.8656   0.6550
Set 17 L 68111   2.3612   0.4700 0.6250

L68149/L68111
$4.40

  L 68149 1.3775   0.6600
Set 36 LM 603012   3.0625   0.6562 0.8437

LM603049/LM603012
$7.25

  LM 603049 1.7812   0.7812
Set 37 LM 603011   3.0625   0.5937 0.7812

LM603049/LM603012
$7.25

  LM 603049 1.7812   0.7812
Set 38 LM 104911   3.2500   0.6500 0.8500

LM104949/LM104911
$7.89

  LM 104949 2.000   0.8750
Set 45 LM 501310   2.8910   0.5800 0.7700

LM501349/LM501310
$8.19

  LM 501349 1.6250   0.7800
Set 46 JL 26710   2.0866   0.4528 0.5709

JL26749/JL26710
$6.64

  JL 26749 1.2598   0.5906
Set 47 LM 102910   2.8910   0.6200 0.7700

LM102949/LM102910
$9.38

  LM 102949 1.7812   0.7800
Set 52 25520   3.2650   0.7500 0.9375

25580/25520
$6.65

  25580 1.7500   1.000
Set 53 25523   3.2650   0.8750 1.0625

25580/25523
$7.95

  25580 1.7500   1.000
Set 54 25520   3.2650   0.7500 0.9375

25590/25520
$7.56

  25590 1.7960   1.000
Set 56 LM 29710   2.5625   0.5500 0.7100

LM29748/LM29710
$8.76

  LM 29748 1.5000   0.7200
Set 61 11520   1.6875   0.3750 0.5625

11590/11520
$7.89

  11590 0.6250   0.5625
Set 63 M 88010   2.6875   0.6875 -

M88048/M88010
$12.16

  M 88048 1.3125   0.8750
Set 69 LM 501314   2.8910   0.6537 1.7724

LM501349/LM501314
$9.65

  LM 501349 1.6250   0.7800
Set 70 LM 29710   2.5625   0.5500 0.7100

LM29749/LM29710
$6.45

  LM 29749 1.5000   0.7200
Set 82 JLM 104910   3.2283   0.6693 -

LM104949/LM104910
$8.46

  JLM 104949 2.000   0.8750
Set 85 25820   2.8750   0.7500 -

25880/25820
$12.49

  25880 1.4365   0.9688
Set 401 572   5.5115   1.1250 1.4375

580/572
$23.89

  580 3.2500   1.4212
Set 403 592A   6.000   1.1875 1.5625

594a/592a
$30.75

  594A 3.7500   1.4300
Set 404 592A   6.000   1.1875 1.5625

598A/592A
$32.25

  598A 3.6250   1.4300
Set 405 653   5.7500   1.2500 1.6250

663/653
$28.78

  663 3.2500   1.6250
Set 406 3720   3.6718   0.9375 1.1875

3782/3720
$10.66

  3782 1.7500   1.1930
Set 407 28622   3.8437   0.7656 0.9688

28682/28622
$16.48

  28682 2.2500   0.9688
Set 408 39520   4.4375   0.9375 -

39590/39520
$22.93

  39590 2.6250   1.1875
Set 410 45220   4.1250   0.9375 1.1875

45284/45220
$25.54

  45284 2.000   1.2188
Set 411 47620   5.2500   1.0313 -

47686/47620
$28.86

  47686 3.2500   1.3125
Set 412 HM 212011   4.8125   1.1700 1.5000

HM212047/HM212011
$19.49

  HM 212047 2.5000   1.5100
Set 413 HM 212011   4.8125   1.1700 1.5000

HM212049/HM212011
$19.76

  HM 212049 2.6250   1.5100
Set 414 HM 218210   5.7874   1.2795 1.5748

HM218248/HM218210
$26.35

  HM 218248 3.5433   1.5748
Set 415 HM 518410   6.000   1.1875 1.5625

HM518445/HM518410
$28.78

  HM 518445 3.5000   1.5625
Set 416 45220   4.1250   0.9375 1.1875

45291/45220
$25.56

  45291 2.2500   1.2188
