Unit
Number |
Shaft
Dia. |
h |
a |
e |
b |
S1 |
S2 |
g |
w |
Bi |
n |
Bolt
Size |
|
|
HCPE 201-8 |
1/2" |
1-5/16" |
5" |
3-3/4" |
1-1/2" |
1/2" |
5/8" |
19/32" |
2-9/16" |
1.713 |
0.669 |
3/8" |
|
|
HCPE 202-10 |
5/8" |
|
|
HCPE 204-12 |
3/4" |
|
|
HCPE 205-14 |
7/8" |
1-7/16" |
5-1/2" |
4-1/8" |
1-1/2" |
1/2" |
5/8" |
5/8" |
2-3/4" |
1.744 |
0.685 |
3/8" |
|
|
HCPE 205-15 |
15/16" |
|
|
HCPE 205-16 |
1" |
|
|
HCPE 206-17 |
1-1/16" |
1-11/16" |
6-1/2" |
4-49/64" |
1-7/8" |
21/32" |
13/16" |
23/32" |
3-9/32" |
1.902 |
0.717 |
1/2" |
|
|
HCPE 206-18 |
1-1/8" |
|
|
HCPE 206-19 |
1-3/16" |
|
|
HCPE 206-20 |
1-1/4" |
|
|
HCPE 207-20 |
1-1/4" |
1-7/8" |
6-9/16" |
5" |
1-7/8" |
21/32" |
13/16" |
3/4" |
3-11/16" |
2.012 |
0.740 |
1/2" |
|
|
HCPE 207-21 |
1-5/16" |
|
|
HCPE 207-22 |
1-3/8" |
|
|
HCPE 207-23 |
1-7/16" |
|
|
HCPE 208-24 |
1-1/2" |
1-15/16" |
7-1/4" |
5-25/64" |
2-1/8" |
21/32" |
31/32" |
3/4" |
3-15/16" |
2.217 |
0.843 |
1/2" |
|
|
HCPE 208-25 |
1-9/16" |
|
|
HCPE 209-26 |
1-5/8" |
2-1/8" |
7-15/32" |
5-3/4" |
2-1/8" |
21/32" |
31/32" |
25/32" |
4-1/4" |
2.217 |
0.843 |
1/2" |
|
|
HCPE 209-27 |
1-11/16" |
|
|
HCPE 209-28 |
1-3/4" |
|
|
HCPE 210-30 |
1-7/8" |
2-1/4" |
8-1/8" |
6-1/4" |
2-3/8" |
25/32" |
31/32" |
7/8" |
4-1/2" |
2.469 |
0.969 |
5/8" |
|
|
HCPE 210-31 |
1-15/16" |
|
|
HCPE 210-32 |
2" |
|
|
HCPE 211-32 |
2" |
2-1/2" |
8-5/8" |
6-23/32" |
2-3/8" |
25/32" |
31/32" |
7/8" |
4-31/32" |
2.811 |
1.091 |
5/8" |
|
|
HCPE 211-34 |
2-1/8" |
|
|
HCPE 211-35 |
2-3/16" |
|
|
HCPE 212-36 |
2-1/4" |
2-3/4" |
9-1/2" |
7-1/4" |
2-3/4" |
25/32" |
31/32" |
31/32" |
5-7/16" |
3.059 |
1.217 |
5/8" |
|
|
HCPE 212-38 |
2-3/8" |
|
|
HCPE 212-39 |
2-7/16" |
|
|
HCPE 213-40 |
2-1/2" |
3" |
10-7/16" |
8" |
2-3/4" |
31/32" |
1-3/16" |
1-1/16" |
5-29/64" |
3.374 |
1.343 |
3/4" |
|
|
HCPE 214-43 |
2-11/16" |
3-1/8" |
10-15/32" |
8-9/32" |
2-27/32" |
31/32" |
1-1/4" |
1-1/16" |
6-3/16" |
3.374 |
1.343 |
3/4" |
|
|
HCPE 214-44 |
2-3/4" |
|
|
HCPE 215-47 |
2-15/16" |
3-1/4" |
10-13/16" |
8-17/32" |
2-29/32" |
31/32" |
1-1/4" |
1-3/32" |
6-13/32" |
3.626 |
1.469 |
3/4" |
|
|
HCPE 215-48 |
3" |
|
