Unit
Number |
Shaft
Dia. |
a |
e |
i |
g |
l |
s |
b |
z |
Bi |
n |
Bolt Size |
|
|
UCFL 201-8 |
1/2" |
4-7/16" |
3-35/64" |
19/32" |
7/16" |
1" |
15/32" |
2-3/8" |
1-5/16" |
1.220 |
0.500 |
3/8" |
|
|
UCFL 202-10 |
5/8" |
|
|
UCFL 204-12 |
3/4" |
|
|
UCFL 205-14 |
7/8" |
5-1/8" |
3-57/64" |
5/8" |
1/2" |
1-1/16" |
5/8" |
2-11/16" |
1-13/32" |
1.339 |
0.563 |
1/2" |
|
|
UCFL 205-15 |
15/16" |
|
|
UCFL 205-16 |
1" |
|
|
UCFL 206-17 |
1-1/16" |
5-13/16" |
4-19/32" |
23/32" |
1/2" |
1-1/4" |
5/8" |
3-5/32" |
1-37/64" |
1.500 |
0.626 |
1/2" |
|
|
UCFL 206-18 |
1-1/8" |
|
|
UCFL 206-19 |
1-3/16" |
|
|
UCFL 206-20 |
1-1/4" |
|
|
UCFL 207-20 |
1-1/4" |
6-11/32" |
5-1/8" |
3/4" |
19/32" |
1-11/32" |
5/8" |
3-35/64" |
1-3/4" |
1.689 |
0.689 |
1/2" |
|
|
UCFL 207-21 |
1-5/16" |
|
|
UCFL 207-22 |
1-3/8" |
|
|
UCFL 207-23 |
1-7/16" |
|
|
UCFL 208-24 |
1-1/2" |
6-7/8" |
5-11/16" |
13/16" |
19/32" |
1-13/32" |
5/8" |
3-15/16" |
2-1/64" |
1.937 |
0.748 |
1/2" |
|
|
UCFL 208-25 |
1-9/16" |
|
|
UCFL 209-26 |
1-5/8" |
7-13/32" |
5-13/16" |
7/8" |
5/8" |
1-1/2" |
3/4" |
4-1/4" |
2-1/16" |
1.937 |
0.748 |
5/8" |
|
|
UCFL 209-27 |
1-11/16" |
|
|
UCFL 209-28 |
1-3/4" |
|
|
UCFL 210-30 |
1-7/8" |
7-3/4" |
6-3/16" |
7/8" |
5/8" |
1-9/16" |
3/4" |
4-9/16" |
2-5/32" |
2.031 |
0.748 |
5/8" |
|
|
UCFL 210-31 |
1-15/16" |
|
|
UCFL 210-32 |
2" |
|
|
UCFL 211-32 |
2" |
8-13/16" |
7-1/4" |
31/32" |
23/32" |
1-11/16" |
3/4" |
5-1/8" |
2-9/32" |
2.187 |
0.874 |
5/8" |
|
|
UCFL 211-34 |
2-1/8" |
|
|
UCFL 211-35 |
2-3/16" |
|
|
UCFL 212-36 |
2-1/4" |
9-27/32" |
7-61/64" |
1-3/16" |
23/32" |
1-7/8" |
29/32" |
5-1/2" |
2-45/64" |
2..563 |
1.000 |
3/4" |
|
|
UCFL 212-38 |
2-3/8" |
|
|
UCFL 212-39 |
2-7/16" |
|
|
UCFL 213-40 |
2-1/2" |
10-5/32" |
8-9/32" |
1-3/16" |
25/32" |
1-31/32" |
29/32" |
6-3/32" |
2-3/4" |
2.563 |
1.000 |
3/4" |
|
|
UCFL 214-43 |
2-11/16" |
10-7/16" |
8-1/2" |
1-1/4" |
25/32" |
2-1/8" |
29/32" |
6-5/16" |
2-31/32" |
2.937 |
1.189 |
3/4" |
|
|
UCFL 214-44 |
2-3/4" |
|
|
UCFL 215-47 |
2-15/16" |
10-13/16" |
8-55/64" |
1-11/32" |
25/32" |
2-7/32" |
29/32" |
6-1/2" |
3-3/32" |
3.063 |
1.311 |
3/4" |
|
|
UCFL 215-48 |
3" |
|
